Alloy Monel 400 Nickel Alloy pipe

Alloy Monel 400 Nickel Alloy pipe

Quick detail:

Similar material grade :UNS:N04400 ,

DIN: NiCu30Fe W-Nr: 2.4360

GB/T: MCu-28-1.5-1.8

BS: NA 12:Ni68Cu28Fe

Size:

Tubes:OD: 1/2“ -3” 12.0-76.2mm

WT:0.02”-0.5” 0.5-12.0mm

Length: Ft 105ft 32 32mt

Pipe: NPS1/2”+-6” 21.34-168.3mm

WT:Sch10-Sch80

WT:2.11-12.7mm

Length 45ft 14mt

Heat exchanger tubes regular size:

Φ19mmx2mm,Φ25mmx2.5mm和Φ38mmx2.5mm Φ25mmx2mm and Φ38mmx2.5mm

Using small diameter tubes can increase heat transfer area per unit volume, compact structure, reduce metal consumption and improve heat transfer coefficient. It is estimated that the heat transfer area can be increased by about 40% and the metal can be saved by more than 20% by changing the heat exchange tube of the same diameter from Φ 25mm to Φ 19mm. But the small diameter fluid resistance is big, inconvenient to clean and easy to block. Generally, large diameter pipe is used for viscous or dirty fluid, while small diameter pipe is used for cleaner fluid.

Production method: Cold drawn and Cold rolled

Application:Heat exchanger,Nuclear Power,Mechanical engineer.

Chemical compostion:

Ni:63.0min

C:0.3max

Cu:28.0-34.0

SI:0.5max

Fe:2.5max

S:0.024max

Mn:2.0max

Alloy Monel 400 Nickel Alloy pipe Images
